MHD Series Heavy Duty Gearboxes

Motovario Gearboxes

Call Us On 01952 676 925 For More On The MHD Series

Email Us On info@gearedmotorsuk.com To Learn More

The Motovario mid heavy-duty gearboxes are engineered for continuous, demanding applications while minimising maintenance costs. These versatile gear reducers combine parallel helical and bevel-helical designs with up to four reduction stages, offering exceptional power density, compact dimensions, and robust performance. Designed to excel in critical and arduous industrial environments, this series provides modularity, reliability, and an impressive performance-to-durability ratio, making it ideal for heavy-duty industries requiring custom configurations and specialised options.

Download Here

MHD Series Features

The heavy duty series offers multiple sizes (179 to 409) and gearing options, including 2, 3, and 4-stage parallel gear reducers and 3 and 4-stage helical bevel reducers, with nominal torque capacities up to 110,000 Nm at 1400 rpm. Input options include P (bell gear and joint) and I (solid shaft), while output configurations range from hollow shafts with key slots or locking units (HC, HL) to cylindrical solid or double solid shafts with keys (CS, CD). Featuring hardened 21NiCrMo2 steel gears, reduction ratios from 6 to 419, and EN-GJS400-15 cast-iron casings, these reducers are built for durability. Finished with RAL 5010 blue water-based paint and a minimum coat thickness of 80 microns, this series combines advanced performance with superior protection against harsh environments.
